Segate Technologies Package Sub Station and LV Switchgear

Client
Segate Technologies
Date
2011
Location
Springtown N. Ireland
Supplied
Packaged Substation
Supplied
LV Switchgear

Kane Engineering has supplied and manufactured the package substation and LV Switchgear as part of the TX7 and SB8 Electrical Infrastructure upgrade at their Springtown Plant.

Project DetailsDownloads

Segate Technologies Package Sub Station and LV Switchgear

HV & Packaged Sub Stations
Low Voltage Switchboards

Kane Supplied:

  • ABB SafeRing CCVV 11KVA 630A 21KA Ring Main Unit C/W battery backup unit RMU and outdoor enclosure.
  • A 2500KVA Cast Resin Transformer (TX7) close coupled with the Main LV Switchboard SB8, with a rated at 4000A 80KA busbar system, 1No 4000A incomer ACB and 10No outgoing feeders rated up to 1600A.
  • A 800KVA Cast Resin Transformer
  • Sub LV Switchboard BS7, rated at 1600A 50KA busbar system, 10No outgoing feeders rated up to 630A
  • Project Details

    Kane Supplied:

    • ABB SafeRing CCVV 11KVA 630A 21KA Ring Main Unit C/W battery backup unit RMU and outdoor enclosure.
    • A 2500KVA Cast Resin Transformer (TX7) close coupled with the Main LV Switchboard SB8, with a rated at 4000A 80KA busbar system, 1No 4000A incomer ACB and 10No outgoing feeders rated up to 1600A.
    • A 800KVA Cast Resin Transformer
    • Sub LV Switchboard BS7, rated at 1600A 50KA busbar system, 10No outgoing feeders rated up to 630A
